VEVOR SS2-200 PEX Heat Transfer Plates 2 ft

VEVOR SS2-200 PEX Heat Transfer Plates 2 ft, Radiant Heat Plates for 3/4″ PEX Pipe, Durable Aluminum & Easy Trimming and Install Underfloor Heat Tubing Plates, Perfect for Wooden Floors (200pcs)

Product Features:

Even Heat Distribution: Tired of the winter chill? This unique U-shaped heat transfer plate is designed to snugly fit with PEX pipes, ensuring even heat distribution across the entire radiant floor. It can reduce heat loss by 30%-40%, maintaining a stable room temperature for your comfort throughout the winter.

Versatile Compatibility: These 2×0.3 ft (600×100 mm) heat transfer plates are suitable for 3/4” (19.05 mm) PEX pipes, including PEX-A, PEX-B, PEX-AL-PEX pipes, with an ID of 0.681” and OD of 0.685”. Before purchasing, make sure to check the dimensions of your plumbing pipes.

Easy Installation: Choose from two installation methods based on your floor structure. Remember to wear gloves and remove the protective film from the heat transfer plate surface before installation to ensure optimal heat transfer. Leave a 1-2 inch gap between two heat transfer plates for long-term stability. You can also trim the plates to your desired length for effortless installation.

Durable Quality: These heat transfer plates are made of 0.016” (0.4mm) thick pure aluminum, which is waterproof, corrosion-resistant, and provides efficient heat transfer. They remain unaltered and can last up to 20 years.

Wide Applications: You can install these PEX heat transfer plates in various radiant heating systems, including between floor joists, sandwiched between layers, or above subflooring (over sleepers). They are suitable for use in living rooms, bedrooms, study spaces, and other wooden-framed or wooden-floored homes with plumbing pipes.

Specifications

Model
SS2-200

Quantity
200 pieces

Suitable PEX Pipe Diameter
3/4” / 19.05 mm

Main Material
Aluminum

Net Weight
33.3 lbs / 15.1 kg

Product Dimensions (per piece)
2×0.3×0.08 feet / 600x100x23 mm
